An end suction centrifugal pump moves fluid by using a rotating impeller to create centrifugal force. Fluid enters the pump axially at the “eye” of the impeller, where it is accelerated outward and its velocity is converted into pressure within the volute casing. This pressurized fluid is then discharged at a 90-degree angle through the outlet.
- End suction back pull out Type centrifugal Pump
- Capacity: up to 1100 m3/hr
- head: up to 150 meter
- size: 25mm to 300mm
- Speed: up to 3500 rpm
- Temperature: up to 350 °C
- MOC: CI, CS, SS 304 / 316, SS 304 L / 316 L, Alloy 20, Hast Alloy B or C , CD4MCU, etc….
MTT Thermic Pumps technical spec
- Bearing assembly design for high safety and maintenance free operation.
- Design technique to ensure long life of bearing and mechanical seal.
- Optimized shaft to ensure reliable removal of leakage.
- Mechanical seal in tandem arrangement.
- Easy for maintenance for its back-pull-out.
- Ideal for thermal oil up to 350°c and hot water 200°c.
- Cooling fins (Air cooled) are provided for cooling the liquid to eliminate external cooling system
water – Up to 750m³/h
water – 8 to 110m
Hot water – 80°c to 200°c
Hot water – 16 bar
Hot water – 960 , 1440, 2880
